Product Overview
The GSC 400VA-2000VA battery backup UPS offers advanced, precise detection and protection functions under digital control. It includes multi-stage automatic voltage regulation (AVR) to handle power irregularities like outages, high/low voltage, surges, and spikes, guaranteeing uninterrupted device operation in the presence of substantial mains voltage fluctuations. The LCD screen shows input/output voltage, load, and battery percentage, elevating the product experience.
Specifications
Model
GSC400
GSC600
GSC800
GSC1000
GSC1200
GSC1500
GSC2000
Capacity
400VA/240W
600VA/360W
800VA/480W
1000VA/600W
1200VA/720W
1500VA/900W
2000VA/1200W
Input
Voltage
220Vac / 230Vac
220Vac / 230Vac
220Vac / 230Vac
220Vac / 230Vac
220Vac / 230Vac
220Vac / 230Vac
220Vac / 230Vac
Voltage Range
140-290 Vac / 140-300 Vac
140-290 Vac / 140-300 Vac
140-290 Vac / 140-300 Vac
140-290 Vac / 140-300 Vac
140-290 Vac / 140-300 Vac
140-290 Vac / 140-300 Vac
140-290 Vac / 140-300 Vac
Frequency Range
>40 Hz (auto adjust)
>40 Hz (auto adjust)
>40 Hz (auto adjust)
>40 Hz (auto adjust)
>40 Hz (auto adjust)
>40 Hz (auto adjust)
>40 Hz (auto adjust)
Output
Voltage (Battery Mode)
220Vac / 230Vac ±10%
220Vac / 230Vac ±10%
220Vac / 230Vac ±10%
220Vac / 230Vac ±10%
220Vac / 230Vac ±10%
220Vac / 230Vac ±10%
220Vac / 230Vac ±10%
Frequency Range (Battery Mode)
50 Hz ±1Hz; 60 Hz ±1Hz (auto adjust)
50 Hz ±1Hz; 60 Hz ±1Hz (auto adjust)
50 Hz ±1Hz; 60 Hz ±1Hz (auto adjust)
50 Hz ±1Hz; 60 Hz ±1Hz (auto adjust)
50 Hz ±1Hz; 60 Hz ±1Hz (auto adjust)
50 Hz ±1Hz; 60 Hz ±1Hz (auto adjust)
50 Hz ±1Hz; 60 Hz ±1Hz (auto adjust)
Transfer Time
2-8ms; 13ms (max)
2-8ms; 13ms (max)
2-8ms; 13ms (max)
2-8ms; 13ms (max)
2-8ms; 13ms (max)
2-8ms; 13ms (max)
2-8ms; 13ms (max)
Waveform (AC Mode)
Sine Wave
Sine Wave
Sine Wave
Sine Wave
Sine Wave
Sine Wave
Sine Wave
Waveform (Battery Mode)
Simulated Sine Wave
Simulated Sine Wave
Simulated Sine Wave
Simulated Sine Wave
Simulated Sine Wave
Simulated Sine Wave
Simulated Sine Wave
USB charger
5V/2.0A MAX
5V/2.0A MAX
5V/2.0A MAX
5V/2.0A MAX
5V/2.0A MAX
5V/2.0A MAX
5V/2.0A MAX
Battery
Battery Voltage
12V
12V
12V
24V
24V
24V
24V
Battery Model & QTY.
4.5AH*1
7AH*1
9AH*1
7AH*2
7AH*2
9AH*2
9AH*2
Maximum Charging Current
1A
1A
1A
1A
1A
1A
1A
Instructions
LCD Display
Power on
Multi-color Switch
Multi-color Switch
Multi-color Switch
Multi-color Switch
Multi-color Switch
Multi-color Switch
Multi-color Switch
AC Mode
Green Light Breathing Blink
Green Light Breathing Blink
Green Light Breathing Blink
Green Light Breathing Blink
Green Light Breathing Blink
Green Light Breathing Blink
Green Light Breathing Blink
Battery Mode
Yellow Light Breathing Blink
Yellow Light Breathing Blink
Yellow Light Breathing Blink
Yellow Light Breathing Blink
Yellow Light Breathing Blink
Yellow Light Breathing Blink
Yellow Light Breathing Blink
Faults
Red Light on Continuously
Red Light on Continuously
Red Light on Continuously
Red Light on Continuously
Red Light on Continuously
Red Light on Continuously
Red Light on Continuously
Protection
full protection
Short Circuit; Overload; Overcharge; Overdischarge protection
Short Circuit; Overload; Overcharge; Overdischarge protection
Short Circuit; Overload; Overcharge; Overdischarge protection
Short Circuit; Overload; Overcharge; Overdischarge protection
Short Circuit; Overload; Overcharge; Overdischarge protection
Short Circuit; Overload; Overcharge; Overdischarge protection
Short Circuit; Overload; Overcharge; Overdischarge protection
Alarms
Battery Mode
Each 10s Onetime
Each 10s Onetime
Each 10s Onetime
Each 10s Onetime
Each 10s Onetime
Each 10s Onetime
Each 10s Onetime
Low Battery
Each 1s Onetime
Each 1s Onetime
Each 1s Onetime
Each 1s Onetime
Each 1s Onetime
Each 1s Onetime
Each 1s Onetime
OverLoad
Each 0.5s Onetime
Each 0.5s Onetime
Each 0.5s Onetime
Each 0.5s Onetime
Each 0.5s Onetime
Each 0.5s Onetime
Each 0.5s Onetime
Faults
Continuous Chirping
Continuous Chirping
Continuous Chirping
Continuous Chirping
Continuous Chirping
Continuous Chirping
Continuous Chirping
Structural Parameters
Size (D x W x H)
255 x 86 x 140 mm
306 x 86 x 140 mm
306 x 86 x 140 mm
345 x 123 x 189 mm
345 x 123 x 189 mm
345 x 123 x 189 mm
345 x 123 x 189 mm
Net Weight (KG)
4
4.7
5.5
8.7
9.6
11.2
11.9
Operating Environment
Temperature Range
0 ~ 90% RH @ 0-40°C (Non-condensing)
0 ~ 90% RH @ 0-40°C (Non-condensing)
0 ~ 90% RH @ 0-40°C (Non-condensing)
0 ~ 90% RH @ 0-40°C (Non-condensing)
0 ~ 90% RH @ 0-40°C (Non-condensing)
0 ~ 90% RH @ 0-40°C (Non-condensing)
0 ~ 90% RH @ 0-40°C (Non-condensing)
Noise
<40 dB @1m
<40 dB @1m
<40 dB @1m
<40 dB @1m
<40 dB @1m
<40 dB @1m
<40 dB @1m
Management
Communication Port
For Choice (USB & RJ45)
For Choice (USB & RJ45)
For Choice (USB & RJ45)
For Choice (USB & RJ45)
For Choice (USB & RJ45)
For Choice (USB & RJ45)
For Choice (USB & RJ45)
