Product Overview
The SK-ST5120 is a Wall-mounted LiFePO4 Battery Pack with an integrated BMS. Rigorously tested for safety and reliability, it offers high energy density and a long lifespan. Suitable for a wide temperature range, it is lightweight and easy to install, catering to diverse energy needs.
Specifications
Model
SKBG5120A
Rated Battery Voltage
51.2V
Electrical Specification
Rated Power
5000W
Nominal Capacity
100Ah
Combination
16S1P
Cycle Life
≥3000cycles@80%DOD @35℃
Monthly Self-discharge
3%/month
Charge Efficiency
≥97%
Discharging Efficiency
≥98%
Charging Standard
Recommended Charging Voltage
57.6V
Recommended Charging Current
20A
Maximum Charging Voltage
58.4V
Maximum Charging Current
100A
Discharging Standard
Maximum Charging Current
50A
Maximum Discharge Current
100A
Discharge Cut-off Voltage
43.2V
Physical
Dimensions (W*D*H) (mm)
520*480*188mm
Package Size (W*D*H) (mm)
590*550*255mm
Net Weight (kg)
46kg
Gross Weight (kg)
49kg
IP Protection
IP30
Shell Material
Metal
Optional Functions
Anti-theft, LCD
Environment
Charging Temperature Range
0°C~45°C
Operating Temperature Range
-20C~60°C
Storage Temperature
0°C~40°C
Humidity
10% to 85% RH (NO condensing)
